MAN TGE 4x4 2017- winch mounting plate

Man TGE 4x4 2017-> mounting plate for winch under the factory bumper. Screwed to the vehicle's frame rails and front suspension beam. Installation does not require drilling or welding. It uses the vehicle's factory screws and threads. The bumper reinforcement beam remains on the car but needs to be cut from the bottom depending on the size of the winch used. Made of 6 mm thick structural steel sheet. Shot blasted and powder coated in a two-layer technology with texture. It has a cutout under the winch drum to facilitate removing dirt from the rope.

Weight approx. 16.2 kg.

Not suitable for vehicles with ACC Adaptive Cruise Control !!!

The plate includes a complete set of mounting elements.

The product does not have homologation.
